Durus 2000

Dump tipper 15.1 t > 121 hp Tandem

The Durus dump trailer is perfect for transporting all kinds of agricultural goods, especially silage, grain, wood chips and other loose bulk materials. The conical body ensures fast and complete unloading. Even heavy materials such as sugar beet, sand, gravel or mud are no obstacle for the Durus. This makes the dump trailer ready for year-round, multi-farm use and economical to operate.

Durus 2000
Key facts
15.1 Load capacity [t]
> 121 Tractor power [hp]
21 Gross weight [t]
Chassis

Sturdy frame made from steel square tube 220 x 220 x 8 mm, tandem chassis with parabolic springs, high drawbar hitch with fixed towing eye D40 mm, hydraulic Y-type parking jack, preparation for trailer coupling, underride guard with commercial LED road lighting system, rear socket, wheel chocks

Durus 2000
Axle / Brakes

Two heavy-duty ADR-axles with 10-stud rims, track 1950 mm, wheelbase 1525 mm, axle load 13500 kg/axle at 40 km/h, brake cam 406 x 140 mm
Dual line air brake installation with ALB (selection according to country)

Durus 2000
Body

Conical dumper body made of steel plate (4 mm floor and 4 mm walls), hydraulic tailgate (with double-acting cylinders and hydraulic accumulator), grain release with lever, inspection window front, steel mud wings, access ladder according to accident prevention regulation (UVV)

Durus 2000
Tipping

Tipping (backwards 50 degrees), 5-level chromed tipping cylinder (90/105/120/140/160 mm), cylinder limit valve, tipping lift height to 2500 mm, required amount of oil of 35.9 litres

Durus 2000

Technical data

Open all plus symbol
DURUS 1600 DURUS 1800 DURUS 2000 DURUS 3000
Basic plus symbol
Permitted gross weight [kg] 16000 18000 21000 33000
Technically permissible gross weight [kg] 16000 18000 25000 33000
Weight without load (depends on config) [kg] 4200 4700 5900 9000
Max. payload [kg] 11800 13300 15100 24000
Max. drawbar load [kg] 2000 2000 3000 3000
Trailer total dimensions (L x W x H) [mm] 7250 x 2550 x 2540 7250 x 2550 x 2540 7950 x 2550 x 2880 9800 x 2550 x 3020
Internal body dimensions (L x W) [mm] 5400 x 2200 / 2300 5400 x 2200 / 2300 6000 x 2200 / 2300 8000 x 2200 / 2300
Platform height (standard tyres) [mm] 1220 1350 1500 1520
Power requirements [kW/hp] > 72 / 97 > 81 / 109 > 90 / 121 > 149 / 199
Body plus symbol
Sidewall height [mm] 1250 1250 1500 1500
Load volume (water level) [m3] 15,0 ~ 21,0 15,0 ~ 22,3 20,0 ~ 31,0 27,0 ~ 42,0
Usable volume (max.) [m3] 17,5 ~ 23,5 17,5 ~ 24,8 22,8 ~ 33,8 31,0 ~ 46,0
Grain release with lever [mm] 390 x 320 390 x 320 390 x 320 390 x 320
Floor thickness [mm] 4 4 4 4
Conical dumper body for easier unloading ● ● ● ●
Frame plus symbol
Frame made from steel square tubes [mm] 260 x 140 x 6 260 x 140 x 6 220 x 220 x 8 300 x 200 x 8
Chrome hydraulic cylinder (levels) 5 5 6 2 x 6
Diameter for every level of hydraulic cylinder [mm] 140 / 120 / 105 / 90 / 75 140 / 120 / 105 / 90 / 75 160 / 140 / 120 / 105 / 90 / 75 140 / 120 / 105 / 90 / 75 / 60
Maximum lift height of hydraulic cylinder [mm] 2500 2500 3000 3500
Required amount of oil for hydraulic cylinder [l] 26,9 26,9 37,6 120
Three-sided tipping angle (side / backwards) [°] 50 50 50 50
Electrical installation according to (EU) 2015/208 with LED technology ● ● ● ●
