GRAVIS 2000

Heavy duty dump tipper icon 14,1 t icon > 127 HP icon Tandem

Because besides bulk and agricultural materials also heavy bulk material like sand, gravel, soil material or recycling material has to be transported more often, professional farmers and contractors will line up their fleet to a wider spectrum of materials. Consequently, Gravis is the powerful machine industry-wide long-term use. The robust construction of the frame unit and the hollow enable a technical payload of approximately 26 tones. The usage of solid, wear material has a positive effect on the working life of the machine. The high-quality serial equipment packages as well as options help the user to keep an overview also in hard working conditions.

Key facts
14,1 Load capacity [t]
> 127 Tractor power [HP]
21 Gross weight [t]
Chassis

Sturdy frame made from steel square tube 300 x 200 x 8 mm, spring-loaded shock absorbers on towing bar, low drawbar hitch with fix towing eye D40 mm (adjustable height, connection height approx. 610/650/690 mm), landing gears (with gear box, double speed, three-stages), preparation for trailer coupling, underride guard with commercial LED road lighting system,, wheel chocks

Axle / Brakes

Heavy duty ADR-axles with 10-stud rims, track 1950 mm, wheelbase 1550 mm, axle load 16500 kg/axle, brake cam 420 x 180 4218E
Dual line air brake installation (selection according to country)

Body

Conical dumper body made of steel plate (8 mm HARDOX®-floor and 6 mm walls), hydraulic tailgate (with double-acting cylinders and hydraulic accumulator), automatic closing for secure locking

Tipping

Tipping (backwards 50 degrees), Front tipping cylinder with cardan bearings and 4 levels (69/88/107/126 mm), double hose system for faster dropping of body, tipping lift height to 2500 mm, required amount of oil of 38,0 liters


Technical data

Open all plus symbol
GRAVIS 2000
Basic plus symbol
Permitted gross weight [kg] 21000
Technically permissible gross weight [kg] 27000
Weight without load (depends on config) [kg] 6900
Max. payload [kg] 14100
Max. drawbar load [kg] 3000
Trailer total dimensions (L x W x H) [mm] 7580 x 2550 x 2876
Internal body dimensions (L x W) [mm] 5250 x 2300
Ground clearance (standard tyres) [mm] 1400
Power requirements [kW/HP] > 95 / 127
Body plus symbol
Sidewall height [mm] 1220
Load volume (water level) [m3] 12,7
Usable volume (max.) [m3] 15,0
Floor thickness [mm] 4
Straight dumper body
Frame plus symbol
Frame made from steel square tubes [mm] 300 x 200 x 8
Chrome hydraulic cylinder (levels) 4
Diameter for every level of hydraulic cylinder [mm] 126 / 107 / 88 / 69
Maximum lift height of hydraulic cylinder [mm] 5100
Required amount of oil for hydraulic cylinder [l] 38,0
Three-sided tipping angle (side / backwards) [°] 55
Elektro installation after (EU) 2015/208 with LED technology
